德国DURBAL关节轴承BRF系列是内螺纹可润滑，低维护，屏蔽适配器尺寸符合DIN648，K系列，带整体调心球轴承的重型杆端
A = 径向游隙 : 10 – 30 μm, 低摩擦力
B = 内圈材料为硬化轴承钢，因为偏转角限制，保护肩及保护壳均为精加工
C = 两侧防尘罩
D = 连杆外壳全部为锻钢, 表面硬化
E = 长期保持润滑状态保证了低维护，特别适用于高速大转角以及高速旋转的场合
选型资料如下:
热销型号如下“
| 型号 | 参数 |
| BRF 06-00-501 | Rod End: Bore 06mm, Thd. 6 X 1.0 mm. |
| BRF 06-00-502 | Rod End: Bore 06mm, Thd. 6 X 1.0 mm. LH |
| BRF 06-60-501 | Rod End: Bore 06mm, Thd. 6 X 1.0 mm Stainless Steel |
| BRF 06-60-502 | Rod End: Bore 06mm, Thd. 6 X 1.0 mm. LH Stainless Steel |
| BRF 08-00-501 | Rod End: Bore 8mm, Thd. 8 X 1.25 mm. |
| BRF 08-00-502 | Rod End: Bore 8mm, Thd. 8 X 1.25 mm. LH |
| BRF 08-00-510 | Rod End: BRF 08 BLANK, NO THREAD |
| BRF 1/1-00-310 | Rod End: BRF 1/1 inch bore Blank (not threaded) |
| BRF 10-00-501 | Rod End: Bore 10mm, Thd. 10 X 1.5 mm. |
| BRF 10-00-502 | Rod End: Bore 10mm, Thd. 10 X 1.5 mm. LH |
| BRF 10-01-501 | Rod End: Bore 10mm, Thd. 10 X 1.25 mm. |
| BRF 10-01-502 | Rod End: Bore 10mm, LH Thd. 10 X 1.25 mm. |
| BRF 10-05-501 | Rod End: Bore 10mm, Thd. 10 X 1.25 mm. Old # BRF 10-01-501 |
| BRF 10-05-502 | Rod End: Bore 10mm, LH Thd. 10 X 1.25 mm. Old # BRF 10-01-502 |
| BRF 10-06-501 | Rod End: Bore 10mm, Thd. 10 X 1.00 mm. |
| BRF 10-06-502 | Rod End: Bore 10mm, LH Thd. 10 X 1.00 mm. |
| BRF 10-60-501 | Rod End: Bore 10mm, Thd. 10 X 1.5 mm. Stainless Steel 1.4034 |
| BRF 10-60-502 | Rod End: Bore 10mm, LH, Thd. 10 X 1.5 mm. Stainless Steel 1.4034 |
| BRF 10-xx-501 | Rod End: XXXX BRF 10 SO, LENGTH (H) 73MM |
| BRF 10-xx-502 | Rod End: XXXX BRF 10 SO, LENGTH (H) 73MM |
| BRF 12-00-501 | Rod End: Bore 12mm, Thd. 12 X 1.75 mm. |
| BRF 12-00-502 | Rod End: Bore 12mm, Thd. 12 X 1.75 mm. LH |
| BRF 12-00-510 | Rod End: Bore 12 mm, BLANK no threads |
| BRF 12-01-501 | Rod End: Bore 12mm, Thd. 12 X 1.25 mm. |
| BRF 12-01-502 | Rod End: Bore BRF 12, LH Thd. 12 x 1.25 mm. |
| BRF 12-04-501 | Rod End: Bore 12mm, Thd. 12 X 1.25 mm.(Old # BRF 12-01-501) |
| BRF 12-04-502 | Rod End: Bore BRF 12, LH Thd. 12 x 1.25 mm. (Old # BRF 12-01-501) |
| BRF 12-05-501 | Rod End: Bore 12mm, Thd. 12 X 1.75 mm.Radial Clearance is 10-20 |
| BRF 12-05-502 | Rod End: Bore 12mm, LH Thd. 12 X 1.75 mm.Radial Clearance is 10-20 |
| BRF 12-60-501 | Rod End: Bore 12mm, Thd. 12 X 1.75 mm. Stainless Steel |
| BRF 14-00-501 | Rod End: Bore 14mm, Thd. 14 X 2.0 mm. |
| BRF 14-00-502 | Rod End: Bore 14mm, Thd. 14 X 2.0 mm. LH |
| BRF 16-00-501 | Rod End: Bore 16mm, Thd. 16 X 2.0 mm. |
| BRF 16-00-502 | Rod End: Bore 16mm, Thd. 16 X 2.0 mm. LH |
| BRF 16-01-501 | Rod End: Bore 16mm, Thd. 16 X 1.5 mm. |
| BRF 16-01-502 | Rod End: Bore 16mm, LH Thd 16X1.5 mm |
| BRF 16-60-501 | Rod End: Bore 16mm, RH, Thd. 16 X 2.0 mm. Stainless Steel 1.4034 |
| BRF 16-60-502 | Rod End: Bore 16mm, LH, Thd. 16 X 2.0 mm. Stainless Steel 1.4034 |
| BRF 18-00-501 | Rod End: Bore 18mm, Thd. 18 X 1.5 mm. |
| BRF 18-00-502 | Rod End: Bore 18mm, Thd. 18 X 1.5 mm. LH |
| BRF 20-00-310 | Rod End: BRF 20 BLANK - NO THREADS |
| BRF 20-00-501 | Rod End: Bore 20mm, Thd. 20 X 1.5 mm. |
| BRF 20-00-502 | Rod End: Bore 20mm, Thd. 20 X 1.5 mm. LH |
| BRF 20-60-501 | Rod End: Bore 20mm, Thd. 20 X 1.5 mm. Stainless Steel |
| BRF 20-60-502 | Rod End: Bore 20mm, Thd. 20 X 1.5 mm. Stainless Steel |
| BRF 22-00-501 | Rod End: Bore 22mm, Thd. 22 X 1.5 mm. |
| BRF 22-00-502 | Rod End: Bore 22mm, Thd. 22 X 1.5 mm. LH |
| BRF 25-00-501 | Rod End: Bore 25mm, Thd. 24 X 2.0 mm. |
| BRF 25-00-502 | Rod End: Bore 25mm, Thd. 24 X 2.0 mm. LH |
| BRF 25-01-501 | Rod End: Bore 25mm, Thd. 20 X 2.5 mm |
| BRF 25-01-502 | Rod End: Bore 25 mm, Thd. 20 X 2.5 mm, LH |
| BRF 25-60-501 | Rod End: Bore 25mm, Thd. 24 X 2.0 mm. Stainless Steel |
| BRF 25-60-502 | Rod End: Bore 25mm, LH, Thd. 24 X 2.0 mm. Stainless Steel |
| BRF 30-00-501 | Rod End: Bore 30mm, Thd. 30 X 2.0 mm. |
| BRF 30-00-502 | Rod End: Bore 30mm, Thd. 30 X 2.0 mm. LH |
| BRF 30-00-510 | Rod End: Bore 30mm, BLANK Threads |
| BRR 08-00-510 | Rod End: BRF 8, BLANK NO THEADS |
| CBRF 20-80-501-00 | Rod End: 20mm BORE, 22 X 1.5 THREAD |
| CBRF 20-80-502-00 | Rod End: 20mm BORE, 22 X 1.5 THREAD, LH |
